Kuvaus
-
-
Engine
Bosch, Performance CX, 250 W, 75 Nm, 25 km/h
-
Display
Bosch, Intuvia
-
Battery
Bosch, PowerTube, 500 Wh
-
Frame family
Winora, Aluminium 6061, multiformed, THT, Aluminium 6061, Disc brake Post Mount
-
Fork
SR Suntour, NCX D-LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8″, Quick release 100mm
-
Crank arm
Winora, forged, Aluminium
-
Brake (front)
Shimano, Deore XT T8000, hydraulic disc brake, 180 mm, 2-piston disc brake
-
Brake (rear)
Shimano, Deore XT T8000, hydraulic disc brake, 160 mm, 2-piston disc brake
-
Tube
Dunlop valve
-
Rim
Ryde, Zac421, hollow rim, Aluminium
-
Clamping ring
Quick release, 34.9 mm
-
Rear derailleur
Shimano, Deore XT M8100 Shadow Plus
-
Shift lever
Shimano, Deore XT M8100, Trigger switch, 12 speed
-
Bottom bracket
integrated in the motor
-
Sprocket
Shimano, SLX M7100, 10 – 51 teeth
-
Chain
Shimano, SLX M7100
-
Brake lever
Shimano, Deore XT T8000, Aluminium
-
Brake disc (front)
Shimano, RT54-M
-
Brake disc (rear)
Shimano, RT54-S
-
Tyre
Schwalbe, Smart Sam, 57-584, 27.5″ x 2.25″
-
Front wheel hub
Shimano, MT400-B, Centerlock
-
Rear wheel hub
Shimano, Centerlock
-
Spokes
Sapim, Leader, black
-
Handlebar
Ergoriser, oversize, 640 mm
-
Grips
XLC, Comfort bo3
-
Stem
Alu, winkelverstellbar, A-head, Bar bore: 31.8 mm
-
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
-
Saddle
Selle Royal, Viento
-
Seat post
Patent suspension, 31.6 mm, Aluminium
-
Pedals
VP, E461, Aluminium, with Reflector
-
Headlight
Herrmans, H-Black MR8 E, 50 lm
-
Rear light
Busch & Müller, Shine Evo, integrated in the luggage carrier
-
Carrier
Racktime, RT-336, 25.0 kg
-
Fenders
Eurofender, Winora schwarz matt, Chromoplastics
-
Stand
Ursus, Mooi, Rear stand
-
Lock
Abus, upgradable over Plus System
-
Weight (kg)
24.1 kg
-
Permitted total weight
130.0 kg
-
